Product Description
Mitutoyo Screw Thread Micrometer with Ratchet Stop
With SPC data output option
Replaces discontinued 326-351-10. Advanced Systems and Designs can offer the Mitutoyo 326-351-30 IP65 coolant proof with interchangeable type anvil-stop tip. Supplied in fitted case.
NOTE: Requires additional anvil spindle tip (optional). Contact us for more information on your specific thread need - Metric, Unified, or Whitworth threads.
Details:
-
60 degree or 55 degree anvil and conical spindle (optional) made of high grade steel, hardened and precision ground. See chart below.
-
Long battery life (1.2 years under normal use)
-
0-1" range with standard
-
+/-.0002" Accuracy
-
Resolution: .00005"
-
SPC data output
-
IP65 Protection
SPC Data Collection Options:
-
To connect this Mitutoyo coolant proof micrometer to our GageMux® gage interface or other devices that recognize the Mitutoyo Digimatic format, click these links to see our 250-521 or 250-522 Mitutoyo Digimatic output SPC gage cable.
-
Click the following link to see our 600-522-KB-USB SmartCable gage interface to send data directly to Excel or other spreadsheet programs from this Mitutoyo gage.
-
This gage is also available for use in the Mitutoyo U-Wave wireless system – click this link for the correct wireless gage cable. See our “Wireless Gage Interfaces for U-Wave” tab for a complete wireless set-up.
Contact us today!
Advanced Systems and Designs can provide all ranges and types of IP65 micrometers from Mitutoyo stock. Contact us for more information.
Anvil-Spindle Tip Set Information:
